Specification

Input

Rated voltage

DC200V

Cut in voltage

100V(100V~150V Adjustable)

MPPT range

DC100V ~ DC300V

Rated power

5kW

Output

Rated voltage

DC48V

Working range

DC40V～DC60V

Output limit current

92A (10～100A Adjustable)

Conversion efficiency

≥92%

Battery management

Low -voltage protection

44V (42V~48V  Adjustable)

Low-voltage recovery

48V (46V~52V  Adjustable)

Float charge voltage

54V (43V~55V  Adjustable)

Are voltage

56V (55V~58V  Adjustable)

Are current

50A (10~100A  Adjustable)

Early warning closed

46V (42V~50V  Adjustable)

Early warning disconencting

50V (46V~54V  Adjustable)

Temprature compensation

0mV(0~7mV  Adjustable)

Load management

Over-voltage protection

60V (58V~62V  Adjustable)

Over-voltage recovery

58V (54V~60V  Adjustable)

Load over current

60A (6～60A  Adjustable)

Communication and monitor

RS485

Can be monitored by line, if with relative module, can be remote monitored.

Environment

Working temprature

-15℃～+40℃

Storage temprature

-25℃～+70℃

Temprature range

<85% ( 25℃士2℃)

Altitude height

<1000m, every 1000m higher, power reduced by 10%
